KTD Hollow super large stroke three-claw chuck
You are here: Home » Power chuck » Hydraulic Chuck » KTD Hollow super large stroke three-claw chuck

KTD Hollow super large stroke three-claw chuck

Crank type three-claw super large through hole diameter and long claw stroke.

The sliding surfaces are hardened, precision finished and directly lubricated.

With the same installation and connection mode as that of hollow chuck, it can be exchanged without changing the pull rod.

High rigid structure and high clamping precision.
Availability:
facebook sharing button
twitter sharing button
line sharing button
wechat sharing button
linkedin sharing button
pinterest sharing button
whatsapp sharing button
sharethis sharing button

Size parameter(mm)

Spec A B C(H6) D D1 D2 E E1 F G max. G2 min. H J
KT06D-3 168 97 140 104.78 82.563 116 5 18 45 1 -12 19 45
KT08D-3 210 114 170 133.35 103.375 150 5 23 52 0 -16 20 52
KT10D-3 254 123 220 171.45 139.719 190 5 18 75 8 -10.5 25 75
KT12D-3 320 126.3 220 171.45 139.719 190 5 18 91 8 11 20 91


Spec Kmax. L L1 M N P Q max. Q min. R max. R min. S T U
KT06D-3 M55x2 6-M10 15 37 73 20 25.75 13.75 39 27 31 12 3-M6
KT08D-3 M60x2 6-M12 18 38 95 25 28.25 16.25 49.25 33.25 35 14 3-M6
KT10D-3 M85x2 6-M16 22 43 110 30 35.25 17.25 64.25 45.25 40 16 3-M6
KT12D-3 M100x2 6-M16 22 50 130 30 45 26 82.5 60 50 21 3-M8



Performance parameters

Spec Plunger Stroke
mm
Jaw Stroke
(DIA.mm)
Max.allowable
thrust
KN(kgf)
Max.Gripping
Force
KN(kgf)
Max.Pressure
Kgf/cm2(Mpa)
Max.Speed
(min-1)
Weight
kg
Moment
of inertia
(Kg m2)
Matching
Cylinder
Max. Pull
Force
(mm)
KT06D-3 13 26 2400 2650 27 3600 14.8 0.063 TK646 Φ10-Φ168
KT08D-3 16 28 3500 4150 26 3000 24.1 0.175 TK852 Φ10-Φ218
KT10D-3 18.5 32 4870 5700 27 2400 43.5 0.347 TK1075 Φ18-Φ254
KT12D-3 19 45 5600(54.9) 4800(47) 30 1500 77 0.8 TK1075 Φ40-Φ304

The above data are the standard parameters, personalized customized solutions can be provided according to customer's requirement.
