Vertical compositis molere machina


A cnc molere machina utitur rotating molere rota ad removendum parva copia materiam ex workpiece. Sunt, primo et principaliter, consummatione machinis. In casu de per opus, a machinist saepe removet significant amounts of materia usura lateris ante transferendo pars ad cylindricum molere machina ad consummatione operationem.

CNC molere est praesertim de tulit off parva amounts of metallum cum summus celeritate abrasive rotating rota agens sicut secans instrumentum. Et molentes rotam circumdurat locum dum pars adfixa apparatus movet in X-, Y- aut Z-axis. Licet motus dependent ex parte figura et mole, molere rota plerumque requirit plures transit ad rectam consummavi dimensionem.

Omnes BDF cnc moles sunt specie configurati, Notulaed et programmed ad sectam finem user scriptor maxime postulans requisita. Nostrum capabilities includit non solum conventional molere, sed princeps celeritate superabrasive molere, ubi nos ducere industria in praecisione et productivity signa.

BDF scriptor unique apparatus features et ingens peritia cum superabrasives praebet felix solutions ad difficile ad Conscidisti materiae ut carbide, tellus, exoticis aerospace Alloys et durum Steels.




Nos providere diversificatur solutions, comprehendo customized ones

Vertical, compositis, molere-machina
CNC vertical compositorum molere machina interner Bores finem facies externa diameter

VM, VHM, DVM Series High-Precision CNC vertical compositum molere machinis sunt verticalis compositum molere machinis cum plena clausa-loop digital potestate independenter disposuerat et developed a comitatu. Et molere machinis habere verticalem layout et geminus-columna structuram. High-praecision Liquid hydrostatic gyratorius mensa est aer-stricta et gerunt, liberum et ut animadverto iam iam servitium vitae et accurate retention tempore.

Rationabile et pacto structural consilio; In workpiece potest clamped semel ad perficere multi-processus molere processus de interiore foraminis. Externo circulo et gradus superficiem, ut partes superioris requisitis pro situ accurate; late in bearings, ventum potentia, constructione machinatione, valvulae, automotive et alia industries.



Peritia in type
Una Fusum Type
Duplex vertical
Unum verticalem et unum horizontalem
Spera popularis

Opus elit et processui capacity



  processus capacitatem:


  • Idoneam id, OD et finem faciem stridor gravibus, non-circularis workpieces.
  • Gravis workpieces potest fixa in fixture per tentorium.
  • Free compositum ex uno fusum, duplex fusum, instrumentum versus aut non instrumentum versus.
  • Facile clamping operationem potest significantly reducere praeparationem pro loading, unloading, alignment etc.
  • Non opus est occasum processus site, automatic compensation of workpiece mole, automatic compensation calculation molere rota positus ultricies.
  • Duplex fusum exempla potest provideri altum et humilis celeritate stridor rotae, aut verticalis et horizontali fusi.




  characteris;


  • Somens 828D cnc ratio adoptavit in machina potest animadverto multi, axis servo imperium.
  • Ad occursum processus requisita, automatic et manual (electronic handwheel) potestate potest ferri ex uterque dispensando elementum partium.
  • Plene inclusum praesidium offerre optimum operabilitatem, maintainability et salus.



 Operating elit ex machina: (User provisum)

Ambientium temperatus: 10-35 ° C; optimal temperatus XX ± II ° ℃;
Relativum humiditas: ≤85%;
Opus Power Supple: Tres-Phase AC 380V ± X%, L ± I% HZ;
Arida mundus Gas Source pressura:  ≥0.7MPA, Rate, Rate: ≥50M3 / h;



  test item accuracy iudicium:


Test item
Test accurate (Manufacturer)
CIRCUMITUS
2.0μm
Cylindrici
2.0μm
Coaxiality
2.0μm
Asperitas
Ra0.4μm
Verticality
2.0μm

Vertical compositis molere machine125 et super fabrica scriptor rotunditate specificationem est 2.0μm
Multi-munus-machining


  Latin accessorium Tools (Shanks - molere rotarum):

 Vertical compositis molere Machina 55/85/125 (in his VI types accessorium instrumenta sunt available)

Latin-accessory-Tools- (Shanks --- molere-rotae)
Et molere rota cum maximum diametrum p CCLV mm (CCCV mm) potest repono in ATC unitas. Tamen, in magnitudine adjacent toolshould limitatur ad CLXXX mm vel minus.
* Vertical compositis molere Machina 85/125



Imperium Panel interface


In terms of imperium panel, dialogo arca archa in 15,6 inch tactus screen ensures magis efficient, user-amica et facilis systeml operationes. In tali user-amica dialogo buxum modus, sicut intrabit in parametri ut progressio statim computat crucem sectionem parametri molendo rota. Forma una key tactus ad generare progressio pro automatic calculation de machining semita et automatic amicientes de molendo rota. De operatione interface possumus videre processui iter et agunt in MOREL Conciso et convenient modo.

Compone molere Machina Imperium Panel Interface
Zhongyan-vertical-molere-apparatus

Typical Exemplum





  Machina specificationem:


Item VM55 VM85 Vm125 Vm160
Basic parametri Workbench Size Φ550 Φ750 Φ1150 Φ1600
Maximum workpiece adductius diameter Φ550 Φ850 Φ1250 Φ1650
Maximum workpiece altitudo (cum fixture) 450 600 600 600
Loadable pondus workbench fusum (kg) 600 1000 5000 4500
Workbench Rotation celeritate XX ~ CCCL VIII ~ CC V ~ C V ~ LXXX
Processus facultatem Foraminis diameter molere range Φ30 ~ φ400 Φ50 ~ φ800 Φ50 ~ φ1200 Φ50 ~ φ1600
Externum circulus molere range ~ Φ500 ~ Φ800 ~ Φ1200 Φ1650
Longitudo Grindable (interiorem tulit) CCXXV (∅ CC vel minus, instrumentum Longitudo CCL)
CCXXV (∅ CC vel magis, instrumentum Longitudo CL)
CCCXXV (∅ CC vel magis, Tool Longitudo CCL)		 CCCXXV (∅ CCL vel minus)
CD (∅ CCL vel, instrumentum Longitudo CCL)
CDLXXXV (∅ CCL vel magis, instrumentum Longitudo CCCL)
Greo longitudinem (externum circuli) CCLXXV (Flat rota molere, ∅ CCLV rota, instrumentum Longitudo CL)
CXXV (inclinavit rota molere, idem Diamer)		 CD (plana rota molere, instrumentum Longitudo CCL) D
(plana rota molere, instrumentum longitudinem CCCL)
CL (inclinati rota molere, eadem diameter)
Molere rota fusum adscendens modum Shank Type Hsk-A63 Hsk-A100 Hsk-A100 Hsk-A100
Externa molere rota fusum Power (KW) 15 15 15 15
Maximus 2500-15000 2500-10000 2500-10000 2000-8000
Turres   Hsk, A63-6t Hsk, a100-6t Hsk, a100-6t Hsk, a100-6t
Linearibus servo axis X Axis Travel 1100 1350 1800 2200
Z axis Travel 660 660 660 700
Velox Travel (M / Min) 0 ~ XV 0 ~ XV 0 ~ XV 0 ~ XV
Pasce resolutio 0.001mm 0.001mm 0.001mm 0.001mm
X Axis positus accurate ≤0.005 ≤0.005 ≤0.005 ≤0.005
X Axis repetere positus accurate ≤0.003 ≤0.003 ≤0.003 ≤0.003
Z-axis positioning accurate ≤0.006 ≤0.006 ≤0.006 ≤0.006
Z-axis repetere positioning accurate ≤0.004 ≤0.004 ≤0.004 ≤0.004
NC Siemens 828d SinMerik 828d SinMerik 828d SinMerik 828d SinMerik
Machina pondus (kg) Pondus retia 14000 16000 19000 22000

* Notes:
I. De superius specifications dantur maxime secundum magnitudinem Gyratorius mensa magnitudine. Instrumentum mutare vel non instrumentum mutare potest etiam electus;
II. Et superius specifications et configurationes potest customized secundum dispensando elit elit.
Zhongyan-vertical-molere-apparatus
Duplex verticalis compositis molere machina

Dual-fusum vertical stridor machina, instructa cum duo fusum, available in summus potentia et humilis-potentia versions, perfectly alloquitur diversitas molere partes, reduces tempus customers habe in crebris instrumentum mutationes et aucta molere efficientiam.






  Machina specificationem:


Item Dvm55 Dvm85 Dvm125 DVM160
Basic parametri Workbench Size Φ550 Φ750 Φ1150 Φ1600
Maximum workpiece adductius diameter Φ550 Φ850 Φ1250 Φ1650
Maximum workpiece altitudo (cum fixture) 450 600 600 600
Loadable pondus workbench fusum (kg) 900 1500 3000 4500
Workbench Rotation celeritate XX ~ CCCL VIII ~ CC V ~ C V ~ LXXX
Processus facultatem Foraminis diameter molere range Φ30 ~ φ400 Φ50 ~ φ800 Φ50 ~ φ1200 Φ50 ~ φ1600
Externum circulus molere range ~ Φ500 ~ Φ800 ~ Φ1200 Φ1650
Longitudo Grindable (interiorem tulit) CCXXV (∅ CC vel minus, instrumentum Longitudo CCL)
CCXXV (∅ CC vel magis, instrumentum Longitudo CL)
CCCXXV (∅ CC vel magis, Tool Longitudo CCL)		 CCCXXV (∅ CCL vel minus)
CD (∅ CCL vel, instrumentum Longitudo CCL)
CDLXXXV (∅ CCL vel magis, instrumentum Longitudo CCCL)
Greo longitudinem (externum circuli) CCLXXV (Flat rota molere, ∅ CCLV rota, instrumentum Longitudo CL)
CXXV (inclinavit rota molere, idem Diamer)		 CD (plana rota molere, instrumentum Longitudo CCL) D
(plana rota molere, instrumentum longitudinem CCCL)
CL (inclinati rota molere, eadem diameter)
Molere rota fusum adscendens modum Shank Type Hsk-A63 Hsk-A100 Hsk-A100 Hsk-A100
Externa molere rota fusum Power (KW) 15 15 15 15
Maximus 2500-15000 2500-10000 2500-10000 2000-8000
 Internum  molere rota fusum Power (KW) 7.5 7.5 7.5 7.5
Maximus 6000-20000 6000-20000 6000-20000 6000-20000
Horizontalis stridor rota fusum Power (KW) 7.5 7.5 7.5 7.5
Maximus 1500-5000 1500-5000 1500-5000 1500-5000
Turres   -A63-4t hsk Hsk-a100-4t Hsk-a100-4t Hsk-a100-4t
Linearibus servo axis X Axis Travel 650 910 1350 1700
X1-axis itinerantur 650 910 1350 1700
Z / Z1 axis Travel 660 660 660 700
Velox Travel (M / Min) 0 ~ XV 0 ~ XV 0 ~ XV 0 ~ XV
Pasce resolutio 0.001mm 0.001mm 0.001mm 0.001mm
X / x1-axis positioning accurate ≤0.005 ≤0.005 ≤0.005 ≤0.005
X / x1, axis repetere positus accurate ≤0.003 ≤0.003 ≤0.003 ≤0.003
Z / Z1-axis positioning accurate ≤0.006 ≤0.006 ≤0.006 ≤0.006
Z / Z1-axis repetere positus accurate ≤0.004 ≤0.004 ≤0.004 ≤0.004
NC Siemens 828d SinMerik 828d SinMerik 828d SinMerik 828d SinMerik
Machina pondus (kg) Pondus retia 14000 16000 19000 22000

* Notes:
I. De superius specifications dantur maxime secundum magnitudinem Gyratorius mensa magnitudine. Una fusum, duplici verticali et verticali et unus horizontali fusi sunt praesto ad arbitrium. Mors Mutare aut non instrumentum mutare potest etiam electus.
II. Et superius specifications et configurationes potest customized secundum dispensando elit elit.





Processus casus

  • Habitatio ferre
  • Built-in molere rota fusum molere profunda pertusum
  • Sleeve genus
  • Paul Series
  • Hydrostatic fusum
  • Hydrostatic fusum
  • Shaft components
  • Habitation Categoria
